- Magnification: 25 X to 1500 X
- Body: Light Weight, latest design with improved system for strain free working. Eyepiece Tube: Inclined at 30 degrees.
- Observation Head: Rota table through 360 degrees. All prisms and optical surfaces are with Anti reflection coating. Inter-pupillary adjustment
- Condenser: Sub stage bright field condenser having numerical aperture N.A.1.25, moveable on rack and pinion with filter holder and iris diaphragm.
- Coarse Focusing: 25 mm / Rotation range.
- Fine Focusing: 2 mm / Rotation range.
- Nosepiece: Quadruple.
- Illumination Lamp: Rating of halogen bulb 6 Volts / 20 Watts.
- Illumination Control: Step down transformer with regulator for variation of illumination in transmission mode is built in microscope.
- Filters: Blue.
- Eye Piece: Hugenian 5 X, Wide Field 10 X, Hugenian 15 X
- Objectives: Achromatic 5X, 10X, 45X spring loaded, 100X Oil immersion spring Mechanical Stage: Fine graduated scales with vernier engraved.
- Free Spare Accessory: Halogen Bulb, Dust /Microscope Cover.
- Storage /Packing: Thermocole Box.
- Guarantee: One Year
