Cast Iron Standard Weights

With firm commitment to quality, we are manufacturing and supplying a comprehensive range of Cast Iron Standard Weight. This range of standard weight sets is highly admired by the patrons for its educational use, general laboratory, industrial, commercial, technical and allied. The R-52 edition of these products are recommended by OIML for simple usage in commercial and trade practices. Available in different weights (50 g, 100 g, 200 g, 500 g, 1 kg, 2 kg, 5 kg, 10 kg, 20 kg and 50 kg) as per the demands of the clients, this range is stacked conventionally and re-verified or re-adjusted periodically.



Specification	The Standard Weight & Measures (General) Second Amendment Rules, 2004
Model	CI-WT-EQ, Accuracy Class of OIML R 111- 1 Edition 2004 (E) : M (Export Quality) 2
Denomination	1000 kg	500 kg	200 kg	100 kg
	160 g	80 g	30 g	16 g
Model No.	CI-WT-SQ, Accuracy Class of OIML R111-1 Edition 2004 (E) : M (Super Quality) 3
Denomination	1000 kg	500 kg	200 kg	100 kg
	500 g	250 g	100 g	50 g
Material	Cast Iron in Body & Mild Steel in Handle
Shape	Rectangular in shape with no sharp edge on corners
Adjusting Cavity	At the side of the Weight

OIML recommended the above vide R-47 Edition 1979(E), for calibration and testing the accuracy of high capacity weighing scales and truck weigh bridges. Cast Iron Rectangular Standard Weights from 100 kg, 200 kg, 500 kg, 1000 kg, 2000 kg, and 5000 kg. These can be stacked conventionally and re-verified or re-adjusted periodically. The control mark as required by law is placed by the seal after adjustment of the weight at the adjusting cavity. All the weights have the handle on the top for easy lifting.
