Fully Automated Coagulation Analyzer

Product Details :

DESCRIPTION

• SF-8050 Automatic Coagulation Analyzer is an automatic instrument for clotting test.
• SF-8050 can be used for clinical test and pre-operative screening.

• SF-8050 adopts clotting and immunoturbidimetry, chromogenic method to test the clotting of plasma.

• The instrument shows that clotting measurement value is the clotting time (in seconds).

• The principle of clotting test consists in measuring the variation in amplitude of the ball oscillation.
• A drop in amplitude corresponds to an increase in the viscosity of the medium.

• The instrument can figure out the clotting time by the motion of the ball.

• The product is made of sampling probe movable unit, cleaning unit, cuvettes movable unit, heating and cooling unit, test unit, operation-displayed unit,

• RS232 interface (used for printer and transfer date to Computer).

• We guarantee each instrument inspected and tested strictly.

• SF-8050 meets country standard, industry standard, enterprise standard and IEC standard.


Features

• Mechanical clotting, immuno turbidimetry, Chromogenic method
• Speed: 200T/H

• Testable items: PT, APTT, TT, FIB, D-DIMER, FDP, AT-III, FACTOR II, V, VII, X, VIII, IX, XI, XII, PROTEIN C, PROTEIN S, vWF, LMWH

• 16 reagent positions and 6 test positions

• 30 sample areas

• 10 incubation areas

• Automatic storage function

• Emergency test Adjustable

• Repeatability: CV (Specimen) =< 3.0%

• Error: ≤5??? or ±2μL, take max.

• Range of sample volume: 10ul-250ul

• Dimension: (L x W x H, mm) 560 x 700 x 540

• Weight: 45kg


Additional Information:

• Item Code: SF-8050
• Delivery Time: 2-4 weeks after order
• Packaging Details: Airworthy Export Packing
