Laboratory Vertical Autoclaves
Product Details:
Automation Grade | Semi Automatic |
Usage/Application | Laboratory |
Brand | Napro |
Shape | Vertical |
Power Consumption | 1-5 kW |
Warranty | 1 Year |
Chamber Volume | 10-15 Litre |
Capacity | 100 LPH |
Material | Stainless Steel |
Voltage | 220-250 V |
Finishing Type | Polished |
Frequency | 50 Hz |
It is used for sterilization under saturated steam pressure at 15 psi. Vertical autoclaves can be either single or double walled units, & are made of thick stainless steel. The lid is made of thick gauge stainless steel having maximum pressure rating 22 psi. Safety features such as pressure gauge, steam release valve & safety valve are provided. Optional foot lifting arrangement provided on larger models.
Specifications & Features:
• Reliable & convenient method of steam sterilization
• Immersion type heater provided for direct heating
• Equipped with pressure gauge, steam release valve & safety valve
• Stainless steel basket supplied for holding the items to be sterilized. Basket made out of stainless steel perforated plate
• Excess pressure release through spring-operated safety valve
• Used for sterilization at working steam pressure up to 15 psi
• Fitted with silicon rubber gasket
• Works on AC 230 Volts power supply
• Foot lifting arrangement can be provided for larger models
Optional Accessories:
• Foot lifting arrangement
• Digital temperature indicator cum controller with timer, 0.1 °c accuracy/resolution
• Digital timer range 0-99 minutes, to count autoclaving time cycle when set pressure is achieved
• Water level indicator
• Low water level cut-off for heater protection
• Pressure cut off switch
• Automatic air purging
• Automatic steam release once autoclaving cycle complete
Size:
• 25 Dia x 45 ht (22 litres)
• 30 Dia x 50 ht (35 litres)
• 35 Dia x 55 ht (52 litres)
• 40 Dia x 60 ht (90 litres)
• 45 Dia x 60 ht (95 litres)
• 45 Dia x 75 ht (140 litres)
• 55 Dia x 75 ht (175 litres)
• 55 Dia x 90 ht (200 litres)
Additional Information:
- Item Code: VA050
