Cryostat Microtome
Product Details:
JINDAL cryostat microtome is designed for sectioning of natural tissue. These are specially designed for clinical and research operations. Sections have the high resolution of cytological details required for pathological diagnosis, histochemistry, fluorescence, biochemistry, microscopy etc. Technique is simple and easy to learn.
Features:
Large Spacious Stainless steel cryo chamber
Anti microbial powder coating with galvanized steel sheet construction
Motorized specimen feed coarse advance with specimen retraction
CFC free refrigerant with noiseless compressor to achieve low temperatures up to -35°C
Heated sliding glass door to prevent condensation
Microprocessor based touch screen operation
Automatic & manual hot gas defrosting
 Easy selection from cutting to trimming by touch of a button
Adjustable cutting angle
Mounted on castors for easy movement
UV sterilization which can be activated by touch of a button
Ergonomic design blade holder with finger guard for safety & anti roll device
Enclosed Drainage system
Encapsulated splash protected microtome
User friendly menu with section counter
Power saving refrigeration system
LED illumination for the cryo chamber
Modular Design Control system:
Chromatic LCD touch screen for user friendly operation
Hibernation automatically/manually, wake up in 15 minutes
UV Sterilization at touch of a button
Peltier cooling station for quick freezing of specimens
Section thickness totalizer with section counter
Slow & fast speeds of specimen feed forward & reverse
Microtome:
Smooth & light handwheel with locking device lever
X-Y-Z 8° specimen orientation triaxially adjustable
Precise durable roller guides made in Germany ensures easy sectioning of hard tissue samples & provides smooth movement
Adjustable retraction & can be turned off
Cryo Chamber:
Large spacious stainless steel chamber with large freezing shelf to hold up to 20 specimen discs
With waste tray & instrument rack
Heat Extractor in quick freeze shelf
Disposable Blade Holder:
Designed to use both High & low profile blades
An anti-fatigue cam lock ensures blades clamp tight
The blade holder can move laterally for safety & to ensure full use of the blade
Glass anti roll device to adjust the angle & gap with the pressure plate
Steel push rod to eject the blade
Technical Specifications:
Temperature of Cryo Chamber: Adjustable Up to -35°C
Temperature of Quick freeze shelf: Up to -45°C
No. of freezing stations: 20
No. of peltier cooled quick freeze stations up to -60°C: 2
Defrost: 1 automatic defrost cycle per 24hr/manual(duration 12 minutes)
Motorized Coarse feed: Slow 600um/sec ; Rapid 900um/sec
Range of Section: Thickness 0.5um to 100um
0.5um – 1um in increments of 0.5um
1um – 10um in increments of 1um
10um – 20um in increments of 2um
20um – 50um in increments of 5um
50um – 100um in increments of 10um
Range of trimming Thickness: 0 to 500um in increments of 5um
0um – 20um in increments of 2um
20um – 50um in increments of 5um
50um – 100um in increments of 10um
100um – 500um in increments of 50um
Total Specimen feed: 28mm
Vertical stroke: 60mm
Maximum specimen size: 55 X 55mm
Refrigeration Capacity: 690W
Refrigerant: R404A ; 300g±5g
Designed to operate on 220V/50Hz AC Supply or 110V/60Hz AC Supply
Input Power: 650 VA
Dimensions of the machine: 780mmL (650mm without handwheel) X 700mmW X 1152mmH
Net Weight: 150Kg.
Optional Features:
Vacuum attachment to prevent rolling of sections
