View Head :
| Seidentopf Binocular Head, Inclined at 30°, interpupilary 75mm Distance 48 Seidentopf trinocular Head, Inclined at 30° |
Eyepiece : | WF 10X/18
P16x/11
Bridge full right image, split-image comparison, superimposed mode; +_3% magnification
compensation of the right side; Magnification of relay system in the bridge 1x. |
Objective :
| Achromatic objective 4x, 10x, 40x, 100x Achromatic Objective 20x, 60x Achromatic Objective 4x, 10x, 40x, 100x. |
Nosepiece :
| Quadruple Nosepiece
Stage 75x40mm Double layers mechanical stage 132x142mm
Stage 75x50mm Double layers mechanical stage 140x140mm |
Focusing :
| Coaxial coarse & fine focus adjustment system
Range 24mm, Fine division 0.004mm |
Condenser :
| NA 1.25 Abbe Condenser with iris diaphragm
NA 1.20 Abbe Condenser with iris diaphragm |
Illumination :
| 3w LED illumination, brightness adjustable halogen lamp 6V/20W |
Filter | Blue filter, green filter |
