Specification
- Brand METZER
- MODEL METZ-777
- MAGNIFICATION 100X - 1500X
- DELIVERY TIME 1-2 WEEKS
Description
- PRODUCT CODE : T/PRD/MRS/MET/002
- Magnification 100x – 1500x
- Illumination The illuminator incorporated 3W LED lamp and has adjustable brightness.
- Objectives Achromatic 10x, 45x & 100x oil (SL).
- Eye Pieces Huygenian 10x & 15x or W.F. 10x.
- Stand A rigid & heavy stand
- Focusing Coarse and fine focusing by conveniently placed separate knobs 1 div. 0.002 mm.
- Condenser Sub stage Abbe filter holder N.A. 1.25 condenser with Iris diaphragm and swing out filter holder focusable by rack & pinion.
- Stages Fixed square stage size 120 x 140 mm. with co-axial graduated Mechanical stage for X & Y movements up to 55mm to 75mm.
- Nose Pieces Triple revolving nose piece with positive click stops.
- Observation Monocular tube 45˚ rotatable through 360˚.
