Specification | ||||
Viewing Head | Monocular Inclined at45°,360°Rotatable | |||
Eyepiece | WF10×/18mm | |||
Objective | Achromatic 4×、10×、40×(s) | |||
Stage | ||||
Double layers mechanical stage Stage size:110mm×126mm Moving range:70mm×30mm | ||||
Condenser | ||||
N.A.1.25Abbe Condenser with iris diaphragm and filter | ||||
Focusing | Coaxial coarse & fine focusing adjustment Fine focusing scale value 0.002mm | |||
Light Source | ||||
Halogen bulb 6V/20W,AC220V/110V | ||||
Optinal Accessory | Eyepiece:WF16×、WF20×、 Objective:20×、60×(s) LED illumination |
