Specification | |||
Viewing Head | |||
Compensation Free Trinoculaar Head, Inclined at 30°(55mm-75mm) | |||
Eyepiece | WF10×/18mm | ||
Objective | Achromatic 4×、10×、40×(s)、100×(s)Oil | ||
Stage | Double layer mechanical stage | ||
Stage Sixe:160mm×140mm | |||
Moving Range:80mm-50mm | |||
Condenser | N.A.1.25 Abbe condenser with iris diaphragm and filter | ||
Fcusing | Coaxial coarse & fine focusing adjustmen Fine focusing scale value 0.002mm | ||
Light Source | Halogen bulb 6V20W or 6V15W, AC 220V/110V Adjustable light source | ||
Optional Accessory | Eyepiece:WF16×、WF20×、P16× Objective:20×、60(s) Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil Reflective Mirror, Demonstration(Teaching) Head Dark field and Phase contrast device 1.3Mega、2.0Mega、3.0Mega、5.0Mega pixels CMOS Digital camera eyepiece Photography attchment and CCD Adapter 0.5×、0.57×、0.75× Compensation Free Binocular & Trinocular Head (48mm-75mm) LED illumination |
