Viewing Head

Sliding Binocular Head, Inclined at  45°(55mm-

75mm)

Eyepiece

Objective

Nosepiece

Stage

Condenser

N.A.1.25 Abbe condenser with iris diaphragm and

filter

Fcusing

Coaxial coarse & fine focusing adjustmen Fine

focusing scale value 0.002mm

Light Source

Halogen bulb 6V20W or 6V15W,  AC 220V/110V

Adjustable light intensity

Optional Accessory

Eyepiece：WF16×、WF20×、P16×

Objective：20×、60(s)、

Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil

Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil、

Reflective Mirror,Demonstration(Teaching) Head Dark field and Phase contrast device

1.3Mega、2.0Mega、3.0Mega、5.0Mega pixels CMOS Digital camera eyepiece

Photography attchment and CCD Adapter 0.5×、0.57×、0.75×

Compensation Free Binocular & Trinocular Head (48mm-75mm)

LED illumination Quintple Nosepiece
