Specification | ||||
Viewing Head | ||||
Sliding Trinoculaar Head, Inclined at 45(55mm- 75mm) | ||||
Eyepiece | WF10×/18mm | |||
Objective | Achromatic 4×、10×、40×(s)、100×(s)Oil | |||
Nosepiece | Quadruple Nosepiece | |||
Stage | Double layer mechanical stage | |||
Stage Sixe:140mm×132mm | ||||
Moving Range:70mm×30mm | ||||
Condenser | N.A.1.25 Abbe condenser with iris diaphragm and filter | |||
Fcusing | Coaxial coarse & fine focusing adjustmen Fine focusing scale value 0.002mm | |||
Light Source | Halogen bulb 6V20W or 6V15W, AC 220V/110V Adjustable light intensity | |||
Optional Accessory | Eyepiece:WF16×、WF20×、P16× Objective:20×、60(s)、 Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil、 Reflective Mirror,Demonstration(Teaching) Head Dark field and Phase contrast device 1.3Mega、2.0Mega、3.0Mega、5.0Mega pixels CMOS Digital camera eyepiece Photography attchment and CCD Adapter 0.5×、0.57×、0.75× Compensation Free Binocular & Trinocular Head (48mm-75mm) LED illumination Quintple Nosepiece |
