Features | a) Steam Temp. 121.4 oC at 15 psi. |
Specification | As per BS 2646-5:1993. Autoclaves for sterilization in laboratories Methods of Test for function and performance.
The Energy from the water is transferred into high pressure steam inside the Stainless steel chamber up to 15-psi pressure or 121.4oC temperature. The Chamber (electrical) is fill with clean water for sterilization. This heat process generated chemical free steam for sterilization. |
Temp Controller | Microprocessor based LCD temp. controller ( GMP model optional ) |
Pressure Controller | Mechanically operated pressure/steam release valve. |
Pressure Gauge | Analog Dial type Pressure Gauge |
Temperature Sensor | Standard coupling type PT 100 Sensor ( GMP model) |
Heat Exchanger | The electrical heat exchanger transfer latent heat to the clean fill water to generated steam under pressure. |
Water Level Control | Low water level cut off electronic circuit protects the electrical heat exchanger from low water level inside the chamber, this Cut's off the power supply to the heat exchanger. |
Steam Outlet | Steam generated from the unit is raised and exits thought the electrically operated steam Purging solonide valve from the outlet ( GMP model) |
