Double Walled Autoclave

Product Details :

We feel immensely pleased to offer an exclusive gamut of Double Walled Autoclave. This autoclave is manufactured by utilizing optimum quality raw material and advanced technology by our skilled professionals. In order to ensure quality, this autoclave is rigorously tested on various parameters. In tune with international standard, we provide the entire product in various sizes and designs, as per the ever-evolving requirements of our clients. Our clients can avail this autoclave from us at market leading prices.

Features:

• Rugged construction
• Corrosion-resistance
• Dimensional accuracy

Constructions:

• Interior chamber is made up of S.S. 304
• Exterior Chamber is also made up S.S. 304 sheet
• Lid Maid up of Stainless steel 304
• Ring is made up of S.S.-304
• Digital temperature indicator/Controller and timer with LED display
• Operating range up to 20psi pressure
• To work on 220/230Volts, 50/60Hz AC supply
• Temp: 121 degree

Accessories Included:

• Automatic pressure control switch
• Automatic Low water cut off device
• Vacuum Breaker
• Pressure Gauge
• Water level indicator
• Safety Valve
• Steam Release Valve
• Paddle lifting Device
• S.S. Basket

Control Panel:

• Microprocessor based digital temperature controller & timer with LED Display
• Simultaneous display of temperature & timer
• Timer starts automatically as soon as the set temperature is attained & stops the cycle
• Automatically as soon the time is over
• The steam is to be released Automatically
• Pt-100 sensor, enabling precise and accurate monitoring in 0.1°C resolution and ±1°c accuracy
• Low water cut off device with alarm facility for safety of heater
• End of the cycle buzzer to alert the user
• Miniature Circuit Breaker for MAINS On/Off plus safety of control panel
• Solenoid Valve for automatic purging and exhaust (as per user requirement)

Specifications:

Model No.	Size of Inner Chamber (Dept. x Dia)	Load	Load
LBS-AC-113	500mm x 300mm (20”x 12”)	2.0 Kw	2.0 Kw
LBS-AC-114	550mm x 350mm (22”x 14”)	3.0 Kw	3.0 Kw
LBS-AC-115	600mm x 450mm (24”x 18”)	4.0 Kw	4.0 Kw
LBS-AC-116	750mm x 550mm (30”x 22”)	6.0 Kw	6.0 Kw

Additional Information:

• Item Code: Digital
