Features
- Double wall design has single chamber for steam and water.
- Fully Automatic operation cycle.
- Initial air purging cycle at the beginning air is automatically removed from the chamber.
- Algorithm developed to control Temp. and proportional pressure precisely at set value.
- Quick Responsive Temperature Sensor.
- In built digital timer – timer can be adjusted as per sterilization load requirements.
- Automatic steam exhaust at the end of cycle
- Low water level heater safeguard.
- Safety high pressure release valve.
- Working chamber made of S.S. LM 304 grade of 2mm thickness.
- Outer cover made of stainless steel 1mm thick.
- Lid, flange & bottom sheet also made of stainless steel. All joints argon welded.
- Single piece made silicon gasket, heavy duty industrial flange heater.
- Designed for Pressure range up to 22 PSI, factory set at 15 PSI.
- Temperature Range : 121 Deg. C to 125 Deg. C.
- Temperature Resolution: 0.1 Deg. C. Temperature Accuracy /- 0.5 Deg. C.
Safety Features.
- Spring loaded pressure valve,
- Steam release valve.
- Hydraulically tested at 60 PSI.
- Electrical Protection: 230 V/15 A/50 Hz.
- Calibration:
- Calibration certificate provided with traceability to National standard.
- Provided with DQ, IQ, OQ Documentation.
