Vertical Triple Walled Autoclave

Product Details :

We are a renowned firm engaged in offering premium quality Vertical Triple Walled Autoclave. The gasket is made using neoprene rubber and the steam jacket is argon-welded and is made using stainless steel. The top lid is made using stainless steel of the best quality. The lid tightening and lid opening is manually handled using a radial locking system and a paddle lifting device, respectively. The water level indicator is fitted on the outer chamber.

Construction:

• For Dry Sterilization
• Digital display of temperature and timer
• Interior & Exterior chamber, boiler & steam jacket are mode of S.S.304 grade
• Middle chamber is made up of Stainless Steel 304
• Lid is made up of Stainless steel 304
• Radial Locking system made of steel bars

Accessories included:

• Automatic pressure control switch
• Automatic Law water cut off device
• Vacuum Breaker
• Pressure Gauge
• Water level indicator
• Safety Valve
• Steam Release Valve
• Paddle lifting Device
• S.S. Basket

Control Panel:

• Microprocessor based digital temperature controller & timer with LED Display
• Simultaneous display of temperature & time
• Timer starts automatically as soon as the set temperature is attained & stops the cycle automatically as soon the time is over
• The steam is to be released manually
• Pt-100 sensor, enabling precise and accurate monitoring in 0.1°C resolution and ±1°c accuracy
• Low water cut off device with alarm facility for safety of heater
• End of the cycle buzzer to alert the user
• Miniature Circuit Breaker for MAINS On/Off plus safety of control panel
• Solenoid Valve for automatic purging and exhaust (as per user requirement)

Specifications:
