Number of Test Channels:

1 to 192 per system

Voltage Ranges:

available up to 180 V maximum

Voltage Accuracy:

0.02% of full scale voltage

Voltage Resolution:

16 bit

Current Ranges:

Single Current Range 1 mA to 2000 A; Four Current Ranges: 150 µA, 5 mA, 150 mA, 5 A

Current Accuracy:

0.02% of full scale current on 5 Amp Multi-range channels

Current Accuracy:

0.05% of full scale current on all other channels

Current Resolution:

16 bit

Time Resolution:

10 mS standard, with 5 mS and 1 mS as an option

Minimum Pulse width:

100 µS

Rise Time:

<500 µS standard in constant current modes, 100 µS or 20 µS optional

Data Recording Rate:

200 data points per second per system standard

Data Recording Interval:

ΔTime (minimum 10 mS standard, 5 mS and 1 mS as an option), ΔV, ΔI, ΔAh, ΔWh, ΔT, ΔP

Operating Modes:

Constant Current, Constant Voltage, Constant Power, Constant Resistance, Voltage Scan (Cyclic Voltametry)

Number of Steps per Test:

127 standard plus subroutines

Step End Conditions:

Voltage, Current, Time, -dV, dV/dT, dV/dt, Ah, Wh, HCAh, HC Wh, LHC Ah, LHC Wh, Auxiliary Voltage, Reference Electrode Voltage, Temperature, dT/dt, dT/dt, pH, Pressure
