Display | 5.7” colour capacitive touchscreen |
Light Source | Pulsed Xenon lamp with 3 year warranty |
Detector | 1024 element CCD array |
Wavelength Range | 190 – 1100nm |
Minimum Volume (dsDNA of in- built sample port) | 0.5uL |
Maximum Concentration of in- built sample port (dsDNA) | 2,500ng/uL |
Detection Limit of in-built sample port (dsDNA) | 1ng/uL |
Path length Accuracy of in-built sample port | +/- 5um |
Wavelength Accuracy | ± 2nm |
Wavelength Reproducibility | ± 1nm |
Spectral Bandwidth | 5nm |
Stray Light | <0.5%T at 220 nm and 340 nm using NaNO2 |
Absorbance Range | - 0.3A to 2.5A (-0.3A to 50A: 10 mm equivalent) |
Absorbance Accuracy | ±0.005A or 1% of the reading, whichever is the greater at 546 nm |
Absorbance Reproducibility | ±0.003A (0 to 0.5A), ±0.007A (0.5 – 1.0A) |
Noise | 0.005A peak to peak 0.002A RMS |
Output | USB port for USB memory stick |
Power input | 90-250V, 50/60Hz, Max 50VA |
Dimensions | 420 x 260 x 185mm |
Weight | approx. 3 kg |
Life Science PC Software | DNA, RNA, oligo, direct UV and colorimetric protein methods, dye labeling efficiency, Tm calculation |
Software Languages | English, Simplified Chinese, French, German, Spanish |
