Core Cutting Machine
Product Details:
Specification :
Core Cutting Machine, diesel engine powered (Grieves Make or equivalent) has been designed specifically for the purpose of cutting core samples from Asphalt, concrete & reinforced structure of roads, airport runways, bridges etc. The Machine comprises of two vertical support columns which carry the drill head/ engine assembly accurately with the help of screwed spindles. The Core Cutting Machine will be supplied with water tank for coolant to the cutting bit. The machine is portable & has towing arrangement with pneumatic wheels for easy movement. The core cutting machine complete as above supplied with Set of Diamond Core Cutting Bit (s) & Barrel (s).
Cat No. & Name | Type of Engine | Capacity of Engine | Cutting Capacity |
AT-242 (a): Core Cutting Machine | Diesel Operated | 4 HP Capacity | 100mm Dia x 200mm Ht |
AT-242 (b): Core Cutting Machine | Diesel Operated | 5 HP Capacity | 100mm Dia x 200mm Ht |
AT-242 (c): Core Cutting Machine | Diesel Operated | 5 HP Capacity | 150mm Dia x 300mm Ht |
AT-242 (d): Core Cutting Machine | Diesel Operated | 5 HP Capacity | 100mm Dia x 200mm Ht 150mm Dia x 300mm Ht |
AT-242 (e): Core Cutting Machine | Diesel Operated | 7.2 HP Capacity | 150mm Dia x 300mm Ht |
AT-242 (f): Core Cutting Machine | Diesel Operated | 7.2 HP Capacity | 100mm Dia x 200mm Ht 150mm Dia x 300mm Ht |
