Box Type Coating Unit
Product Details:
Box type coating unit consists of
Stainless Steel Box type chamber with fully openable hinged door to house electron beam gadgetry, sensors and controllers. High Vacuum pumping system with diffusion pump backed by a suitable rotary pump, Foreline trap, necessary plumbing line and protections, vacuum measuring gauges. Automatic vacuum controller for automatic vacuum cycling with manual over riding facility Electron beam gun with suitable electrical feedthrough, water cooling facility, current indexer and installation kit. Air cooled electron beam power supply capable of supplying power to 1/2/3 electron beam source with necessary cables Programmable sweep controller to control the position amplitude and frequency of the electron beam sweep in lateral and longitudinal axes. Quartz Crystal Thickness monitor Kaufman type ion source with power supply to facilitate either ion beam assisted deposition or ion beam sputtering from a given target. Ion cleaning facility, Air operated source shutter Substrate rotation, heating and cooling facility and air admittance and gas purging facility. Standard interlocks and safety mechanism.
