BIOLOGICAL SAFETY CABINET CLASS III
Product Details:
Special Features
- Reduced cost.
- Slow voice.
- User friendly Ergonomic design
- Controlled environmental bias free product protection.
- The work area is surrounded by negative security, double wall planners for safety.
- Aerodynamic designed airflow grills protect the block by blockage.
- Silent vibration - free operation to ensure blower
- Sound level no more than 65 dbA
- The unit is suitable for class 100 position.
- 100% of the air is transmitted through the HEPA filter.
- Filtered Exhaust - Protects the ambient environment, and avoids particles produced in the air.
- The exit of the safety cabinet is linked to the virus burnout unit to protect the product and personnel.
- The air is pulled through the pre-filter and it is made to pass through the high effective HEPA (High efficient air filter) filter.
- The efficiency of the HEPA filter is more than 99.97% to 0.3 microns.
- Original material of thick board wood front back top and outer surfaces are covered with Formica.
- Or cold rolled steel duly powder coated or stainless steel (SS-304) (as ordered).
- The working table is made of stainless steel sheets (SS-304 grade).
- Window with predefined locking device opens up to 20 cm + 5 mm height of working.
- Made in U.V. Germicidal Lights - The sterilization facility of the work area before and after use.
- Cock - For gas, air or vacuum, (only 1 no.) Is provided.
- The work area is illuminated by the fluorescent light in the unit.
- The blower and motor assembly is statistically and dynamically balanced from 1/5 H.P. Capacity works with a minimum noise level.
- The work table provides the working condition of comfortable "SIT down" for the operator.
- Single phase 220/230 volt AC. Full supply with cord and plugs to work on the supply.
Model No | RSI/BSC-22 | RSI/BSC-32 | RSI/BSC-42 | RSI/BSC-62 |
Working Table Size | 2' x 2' | 3' x 2' | 4' x 2' | 6' x 2' |
Working Size | 2' x 2' x 2' | 3' x 2' x 2' | 4' x 2' x 2' | 6' x 2' x 2' |
HEPA Filter Size | 2' x 2' x 6" | 3' x 2' x 6" | 4' x 2' x 6" | 3' x 2' x 6" |
No. of Motor/Blower | 1 | 1 | 1 | 1 |
Illumination | 1 x 40 w | 1 x 40 w | 2 x 40 w | 2 x 40 w |
Cabinet Materiel | Wood or Cold Rolled Steel Powder Coated or Stainless Steel (SS-304) | |||
Work Table | Stainless Steel (SS-304 grade) | |||
View Window | In the work room for sampling of samples | |||
Main Filter | HEPA Filter (99.97% efficient at 0.3 micron particles) | |||
Pre-Filter | High efficiency pre-filter (Washable) | |||
Sterilization | By U. V. Germicidal Tube in work area | |||
Manometer | Static pressure analogue type. | |||
Sliding Sash | Counter balanced door for seamless operation | |||
Noise Level | Less than 65 db | |||
Standard Accessory | Gas/Air cock and Multipoint 15/5 Amp. electric socket | |||
Electric Supply | AC 230V, 50/60Hz |
