Displacement, Velocity, Acceleration Measurement Setup

Process Control Trainers

SPECIFICATION
The Displacement, Velocity & Accelaration Measurement Setup (52273) for Vibration Measurement using Accelerometers outlines basics regarding Vibration Measurement.

Features
Compact Ergonomic Design.
User Friendly, Self Explanatory Systems.
Leak proof Safety Measures, robust construction.
Enhanced Electrical Safety Considerations.
Training Manuals mimic Charts for Operation Ease.
Facility to ‘Freeze’ the reading.
Inbuilt Safety Measures to avoid improper usage.

Experiments
Study of Vibration Measurement Using Accelerometer.
Study of measurement of displacement, Velocity & Acceleration.
System Components
Electric operated vibrating platform.
Sensor-Piezo Electric Accelerometer.
3 ½ digit LCD Display.
600-60,000 r.p.m. Response.
0-2000 Microns peak-to-peak Displacement Measurement.
0-200-mm/sec-peak velocity measurement.
0-19.99 m/sec2. Acceleration.
Powered by 6 X 1.5 V (R-6) Battery.

Services Required
Electric supply: 1φ 230 V AC, 50 Hz.
