FUME HOOD
Product Details:
Special Features
- Low Cost.
- Low Noise.
- User Friendly Ergonomic Design.
- Generates a negative pressure inside the hood, allowing it to remove all contaminated substances from the work area in the atmosphere.
- Original material of thick board wood front back top and outer surfaces are covered with formica. Or cold rolled steel duly powder coated or stainless steel (SS-304) (as ordered).
- All internal surfaces are sealed and checked for leakage.
- Work table is made of Granite and a small S.S. with water tap connection. Has been installed with sync.
- Work area has been fitted to the unit by fluorescent light.
- The front door hiding counter moves up and down with balanced weight.
- The bellows and motor assemblies are statistically and dynamically balanced and operated with a minimum noise level.
- The work table provides the working condition of comfortable "SIT down" for the operator.
- Front facing panel has been installed with a 15/5 amp. socket with the switch for the exhaust system and fluorescent light.
- Supplied complete with cord & plug to work on Single Phase 220/230 volts AC. supply.
Model No: | RSI/FH-51 | RSI/FH-52 | RSI/FH-53 | RSI/FH-54 |
Working Table Size | 2' x 2' | 3' x 2' | 4' x 2' | 6' x 2' |
Working Size | 2' x 2' x 2' | 3' x 2' x 2' | 4' x 2' x 2' | 6' x 2' x 2' |
No. of Motor/Blower | 1 | 1 | 1 | 1 |
Illumination | 1 x 40 w | 1 x 40 w | 1 x 40 w | 1 x 40 w |
Construction | (Work Table ):- Granite | |||
Lighting | Fluroscent light with vapour- Proof for proper illumination. Intensity Approx 400lux on work top. | |||
Motor | 3 Phase TEFS, IP55, Class F continuous rated. / Single phase. | |||
PVC Fume Duct Size | 6 inch | |||
Working Table Top | Fitted with acid/alkali resistant tile and p.p sink fitted with swan type water tap. | |||
Sash (Shutter) | Vertical rising sash counter – balanced with pulley & counter weight system. Toughned float glass (4mm tick) clear open able height of 700mm. | |||
Maximum air exhaust air volume | Minimum face velocity of 0.5m/s or 100 fpm at defined sash position | |||
Front Door | Moves vertically up and down with concealed counter balanced weight/by Hinges | |||
Standard Accessory | Gas/Air cock fitted with 15/5 amp 3pc socket with switches | |||
Electric Supply | AC 230V , 50/60Hz |
