OPEN PAN EVAPORATOR APPARATUS

Product Details:

Brand

saini

Description The present set-up is designed to study the heat transfer in forced convection. It consists of a test pipe surrounded by a heater externally and fitted with a blower unit with valve for varying the air flow rate. Four Temperature Sensors are embedded on the test section and two are placed in the air stream at the entrance and exit of the test section. A digital temperature indicator measures the temperature profile along the test section. An orifice with manometer is fitted on the delivery side of the blower to measure the flow of air. A Digital Temperature Controller is provided to have an automatic smooth control on required heat input to the heater as per user requirements. Further steady state of experiment is achieved in very less time as compared to manual control. Electronic energy meter is provided to measure the heat input.
 • Experimentation/Learning Objectives
• To determine average surface heat transfer coefficient for a pipe by forced convection.
• Comparison of heat transfer coefficient for different air flow rates and heat flow rates.]
Utilities Required
• Electricity Supply: 1 Phase, 220 V AC, 50 Hz, 5-15 Amp combined socket with earth connection (Earth voltage should be less than 5 volts)
• Floor area: 1.2 m x 0.5 m.
Technical Details
• Test section : Horizontal, externally heated Diameter : 28 mm (approx.) Length : 400 mm (approx.)
• Blower : FHP of Standard make.
• Heater : Nichrome Wire.
• Air Flow Measurement : Orificemeter & Manometer.
• Control panel comprising of : Digital Temperature Controller : PID Controller, 0-199.9° C. Energy meter : Digital Type for power measurement. Digital Temp. Indicator : 0-200°C, with multi-channel switch. Temperature Sensors : RTD PT-100 type-6Nos. With standard make On off switch, Mains Indicator etc.
• An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
• The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.
