MODEL

LXBI001

LXBI002

LXBI003

LXBI004

Internal Dimension (WXDXH) (mm)

300x300x300

355x355x355

455x455x455

455x455x605

Capacity

28 ltrs

45 ltrs

95 ltrs

125 ltrs

Heat Load

0.50 KW

0.50 KW

1.00 KW

1.00 KW

No. of Shelves

2

2

2

2

Temperature Range

Ambient to 60OC

Circulation

Available with or without Air Circulating Fan

Temp. Controller

Microprocessor based PID Digital Temperature Indicator cum Controller with LED Display

Temperature Accuracy

+1 OC

Temp. Display

Digital LED

MODEL

LXBI005

LXBI006

LXBI007

LXBI008

LXBI009

Internal Dimension (WXDXH) (mm)

605x605x605

605x455x910

610x610x910

610x910x910

910x910x910

Capacity

224 ltrs

252 ltrs

336 ltrs

500 ltrs

750 ltrs

Heat Load

1.50 KW

1.50 KW

1.50 KW

2.75KW

3.0 KW

No. of Shelves

2

3

3

3

3

Temperature Range

50OC to 70OC +1 OC

Forced Convection

Available with forced convection system (Standard Features)

Temp. Controller

Microprocessor based PID Digital Temperature Indicator cum Controller with LED Display

Display

Digital LED
