Stackable Incubator Shaker Model - Manthan IS15 ( Can be stacked up to 2 units )
Product Details :
| Capacity | : | 18 clamps of 250ml flasks or 09 clamps of 500ml flasks or 05 clamps of 1000ml or 01 clamp of 5000 ml. ( select any one ). threaded holes to hold assorted clamps. |
| Platform Size | : | 16" x 14" |
| Working Chamber | : | D x W x H = 16" x 18.5" x 16" |
| Overall Dimension | : | D x W x H = 22.5" x 33.5" x 24" |
| Shaking Orbit | : | 12.5mm or 25mm ( customized orbit available on request ) |
| Speed | : | 500 RPM @ 12.5 mm orbital stroke 400 RPM @ 25 mm orbital stroke |
| Control system | : | Microprocessor based control system or HMI PLC with data logging facility provided ( optional ) |
| Temp. Range | : | 20 Degree Celsius below ambient to 60 Degree Celsius ( Mini temp 5 degree Celsius ) |
| Temp. accuracy | : | ( ± ) 0.2 Degree Celsius or better |
| Temp. Uniformity | : | ( ± ) 1 Degree Celsius or better |
| RPM Accuracy | : | ( ± ) 2 RPM or better |
| Alarm | : | temperature overshoot & undershoot alarm provided. |
| Mechanism | : | Heavyduty longlasting mechanism with both obital & linear motion. |
| Illumination | : | Inspection lamp provided. Illumination unit for photosynthesis can be provided ( optional ) |
| Power required | : | 230V, 50Hz single phase, 15amp stabilized. |
