Thermal Ageing Oven Cable

Product Details :

Thermoplastic & elastomeric insulation & sheath exposed to heat are subjected to many types of physical & chemical changes. The severity of exposures, both in temp. & time, determines the extent & type of change that takes place. This test makes an assessment of change in tensile strength and elongation of materials on subjecting them to accelerated ageing in air.Oven designed to provide 8-20 changes of air per hour, at controlled temp. and extended duration up to 72 hours or longer.PID temp. controlled for an accuracy better than± 20°C. Temp. range upto 190°C, higher temp. available on request.Conforms to IS:10810 (Part-11), IS: 5831, IEC:540 & other intl. standards.Fitted with Hour-meter.Also available Single Cell Model.
