Zonotech Water Bath Incubator Shaker
TECHNICAL SPECIFICATION
SHAKING MOTION : RECIPROCATING / ORBITAL
- Water bath incubator shaker is of sturdy construction with outer body made of mild steel sheet duly powder coated and inner chamber made of stainless steel grade 304.
- The gap between the inner and outer chamber is filled with effective insulation.
- Temp. is controlled by Microprocessor PID Temp. controller, with dual display of temp.(process&set value).
- A variable speed motor is fitted to provide shaking of the tray. the speed of the motor can be varied through a stepless electronic regulatorfitted in the panel.
- The shaking tray moves on four wheels / balls (Reciprocating). Eccentric Cam (Orbital).
- With Digital RPM Indicator (optional)
- in Refrigerated Model, Temp. below ambient is achieve by hermetically sealed CFC FREE compressor (lSl Mark) placed below the water bath with other refrigeration accessories.
- For above ambient temp. stainless steel immersion type heating elements are provided inside the bath.
- The bath is provide with a stainless steel pyramidical shaped lid and a drainplug. Supplied complete with one shaking rack of 100ml conical flasks.
OPTIONAL
- Shaking Racks for MMI - 100 (1) & (2)
- 16 No. x 25ml. Conical Flask
- 12 No. x 50ml. Conical Flask
- 9 No. x 100ml. Conical Flask
- 5 No. x 250ml. Conical Flask
- 4 No. x 500ml. Conical Flask
- 2 No. x 1000ml. Conical Flask
- 20 No. x 25mm dia test tube
- Shaking Racks for MMI - 100 (3)
- MMI - 100C & MMO - 200
- 20 No. x 25ml. Conical Flask
- 16 No. x 50ml. Conical Flask
- 12 No. x 100ml. Conical Flask
- 9 No. x 250ml. Conical Flask
- 6 No. x 500ml. Conical Flask
- 4 No. x 1000ml. Conical Flask
- 30 No. x 25mm dia test tube
MODEL | SHAKING TRAY (L×W×D) mm | Temp. Range and Accuracy | RPM | SHAKING TYPE |
BWB-100 | 1) 275×275× 75 | Ambient + 5°C-100°C±O.1°C | 30-150 | RECIPROCATING |
275×275× 150 | ||||
400×300× 150 | ||||
BWB-100C | 400×300× 150 | 10°C - 90°C ± 0.1°C | 30-150 | RECIPROCATING |
BZO-200 | 400×300× 250 | Ambient + 5°C-100°C±O.1°C | 30-200 | ORBITAL |
BZO-200C | 400×300× 250 | 10°C - 90°C ± 0.1°C | 30-200 | ORBITAL |
