|Air Flow Adjustment||Needle valve (long taper)|
|Usage||Film Circumrotate Oven|
|Air Pressure Gauge||Range 0 - 100 PSI|
Rolling Thin Film Ovens provide chamber temperatures with minimal overshoot for measuring the effect of heat and air on a moving film of asphalt binder. This simulates short-term aging during production, handling and paving operations as a controlled flow of heated air is directed into rotating glass bottles. Rolling thin film As per ASTM D2872.
Units feature a PID controller. A solid-state digital temperature controller with built-in over-temperature protection and 200 Watt heating controls temperature to ±1°F at 325°C (±0.5°C at 163°C). Ovens have enameled steel exterior and double-wall construction.
Chamber temperature with minimal overshoot
Dual four-digit display provides simultaneous view of actual & set point temperatures
Solid-state digital temperature controller controls temperature to ±1°F at 325°C (±0.5°C at 163°C)
Rolling Thin Film Oven
Eight RTFO Bottles
Stainless steel tongs with gripper pads for easy handling of hot bottles
additional specimen bottles
Cooling Rack holds nine specimen bottles
Bottle Scraper for removing interior film
