Upright Freezer Double Door

Product Details :

Upright Freezer Double Door LUFD-30-301

DETAILS

• Sheet steel epoxy coated white colour inside and outside
•  Internal corners are rounded for easy cleaning
• High density polyurethane insulation

• Insulation thickness: 50-75 mm

• Hinged door side-by-side provided with removable magnetic rubber gasket and flush-fitting type door handle

• 6 storage open wire shelves realized in sheet steel with a strong plastic coating

• Internal lighting: 2 bulb mounted in the bottom part of the control panel with automatic activation at every door opening through a special switch

•  Control panel: Microprocessor operating with soft-touchpads and LCD display. The main functions of the control panel are:

• Digital temperature display with an accuracy of 0.5°C

• Keyboard password protected with automatic locking
• Back-up battery, with automatic recharging, granting till 48 hours autonomy for the control panel functioning in case of power failure
• Muting facilities for the acoustic alarms
• Test facilities for both battery charging status and alarm limits
• Alarms memory (not deletable) for the last 30 alarm conditions
• Icon based menu
• Real-time graphical temperature chart
• Data-logging function through USB port with direct download of Excel file
• GSM/GPRS telephone dialer
• Events memory with the possibility of checking from the display, defrostings, door openings, relays status, etc.
• Pt1000 sensors for a better accuracy of the temperature control
• Internal ventilation setting
• Cooling unit: Condenser compounded by a hermetic compressor and an air cooled condenser

• Refrigeration: forced-air circulation

• Refrigerant: CFC-free

• Defrosting: Completely automatic, thermostat controlled

• RS 485 Interface

• Plug: Schuko type

• Noise level (dB (A)): ≤ 58

• Safety functions: Visual and acoustic alarm signaling (with automatic resetting) forhigh and low temperature with limits programmable from the user, door ajar, delayed to allow the standard operations, power failure, anti-freezing evaporator, sensors failure


SPECIFICATION

Capacity	925 L
Temperature Range	-15°C to -30°C
Shelf Loading Capacity	30 kg
Shelf Dimension (WxD)	460x570 mm
Overall Dimension	1200X740X1920 mm
Power Supply	220V/50Hz
Weight	220/250 kg
Catalog No.	9428220181

APPLICATION

Labocon Upright Freezer Double Door LUFD-30-300 Series are suitable for storage of number of samples like plasma and test samples to biologicals, storage of life-saving and frozen blood supplies and vaccines, enzymes for genetic research, temperature sensitive materials, reagents and other media.

Additional Information:

• Item Code: LUFD-30-301
