SPECIFICATIONS :

• High product protection by provision of ISO Class 5 particle free work area
• Two Stage filtration Construction = 304 , 18/19/16 swg
• EU6 – Prefilter (95% down to 5 micron)
• Hygieno brand pre filter
• EU14 - HEPA Filter – Supply (99.999% down to 0.3 micron)
• AAF brand hepa filter
• Dynamically balanced Motor-blower provided with suspension arrangement to minimize the noise level
• Meghnehelic Pressure Gauge : 1 No.
• On / Off Switch for Motor
• SS 304 work table with due reinforcement
• Tough glass side panels
• Fluorescent Light with milky white diffuser (250 Lux)
• 5/15 Amp single-phase switch socket for external equipment
• DOP Test Port
• OPTIONS AND ACCESSORIES :
• Front doors (hinged)
• U. V. Light with Hour Meter
• Air / Gas Cock
• Night Mode Operation
• Audio / Visual alarm for blower tripping with Fault Acknowledgement & Reset Switch
• 1 – Piece / foldable polycarbonate front door

OPERATING CONDITIONS :

• Power Supply : 230V AC 1-Ø 50HZ / single phase
• Air cleanliness -ISO Class 5 (ISO 14644-1:1999 (E))
• Air Velocities 0.45 ± 0.05 mps
• Air Flow -Horizontal
• Noise Level Less than 67 dB
• Vibration Level- Minimum
• Power Supply 230V AC 1-Ø 50HZ
