DIGITAL TEMP. CONTROLLER

In this improved model, ceramic fiber wool insulation (instead of brick insulation) has been provided resulting in weight and size reduction of furnace. The weight and size of the furnace is ¼ and 30% respectively as compared to brick furnace. The heat up time is less. heat loss is very low-resulting in power saving.

SPECIFICATION

Construction: CRS sheet with staving enamel

Insulation: Ceramic fiber wool insulation

Working Temp: 1100°C

Temp. control: Dual display microprocessor based Digital temperature indicator cum Controller with Cr/A1 sensor.

Headings: KANTHAL A-1/Nichrome wire in Coil form wound on the muffle, Embedded in high grade refractory Cement.

Std. Fittings: Compensating cable, indicating lamps, Power plug and cord.

Operation: 220/230 Volts AC single phase.
