Advanced BrinellHardnessTesterHT 3000H-3000PC

Product Details :

Electronic Brinell hardness removes the hanging weights, more precision and repeatability, stable performance, the machine appearance is beautiful, has a high-cost performance, are widely used in the factory workshop and laboratory.

Main Features

• Equipped with sophisticated sensors and a micro control system, dynamic force value fluctuation is less than 1/1000, test results are more accurate.
• It possesses the 10 types of test forces, it can test 10 Brinell scales, with wider test range
• Equipped with high performance of servo motor which automatically | load/unloading. It cause the less noise when do test.
• The outer body of machine is formed by special one-time casted technique, has stable structure, it is not easy to be out of shape, can work under relatively harsh environment.
• . With pure white car painting and its class is high, have scratch resistance Felis Mie etmelalelai car-e Be) mt Lee
• This machine can connect to portable Brinell image software, improving the efficiency (optional).

Main Application

• Brineel Hardness Taster is desinged for Brinell hardness measurement on steels and other
• ferrous materials and also on non ferrous materials like Brass, Bronze, Aluminium etc
• material can be cast, forged or lled and the shape cane be flat, round or irregular.

(Brinell Analysis Software Impression Diameter)

• (Brinell Impression Diameter Analysis Software) is a handy instrument to measure the diameter of Brinell impression. With this hand held instrument entire sequence is very simple.

Features

• Auto measurement Mode
• Hardness curve graph
• Hardness conversion
• Statistical Calculation
• Geometry measurement
• Hardness value read - Using Software BrinellMicopcrose
• Machine Size And Weight - 530x187x758mm (LxWxH) 135kg
• Standard Accessories - 2.5, ©5, 610mm Ball Indentor : 1No.
• Optional Accessories - Computerized Brinell Impression Measuring system; Brand computer & printer.
