BRINELL HARDNESS TESTER
Product Details :
The machine is designed with a Hydraulic Power pack and control circuit for effortless loading unloading operation. A dial gauge in from measures depth of ball penetration. This facilitates production testing within tolrance limits by comparison method.
STANDARD ACCESSORIES
Testing Table 200 mm Ã~ | 1 pc. |
Testing Table 200 mm Ã~ with 'V'
grove for | 1 pc. |
Ball holder 5 mm | 1 pc. |
Ball holder 10 mm | 1 pc. |
Test block HB-5/750 | 1 pc. |
Test block HB 10/3000 | 1 pc. |
Brinell Microscope | 1 pc. |
Allen Spanner | 1 pc. |
Telescopic cover for elevating screw protection | 1 set |
Instruction Manual | 1 book |
TECHNICAL SPECIFICATION
Max load (kgf) | 3000 |
Load range (kgf) | In stage of 250 kgf |
Initial Load range
(kgf) | 250 |
Max. test height
(mm) | 410 |
Depth of throat (mm) | 200 |
Size of base (mm) | 670 x 370 |
Machine height (mm) | 1127 mm |
Nett. weight
(Approx. Kg. | 450 kg |
Test Performed | Brinell |
BRINELL HARDNESS TESTER
