Non-Dispersion Infrared Gas Analyzer
Product Details:

Model Name/Number	ZRE
Brand	Fuji Electric
Usage/Application	Continuous Emission Monitoring System (CEMS)
Product Type	Gas Analyzer
Power Supply	110VAC - 240VAC, 50Hz / 60Hz
Features	Multiparameter capable of measuring 5 component
Analysis Time	45 Sec
Color	Gray
Automation Grade	Automatic
Display Type	LCD Type
Response Time	20 Sec
Weight	8 Kg
Temperature	0 - 50 DegreeC
Humidity	90% RH max.
Measurement Gas Pressure	0.1 Bar or Less
Measuring Range	0 - 100 ppm To 0 - 100% Vol, Selectable
Sample Gas Flow	0.5 LPM
Dimension	133mm (H) X 483mm (W) X 418mm(D)
Analog Output	12Nos
Make	Fuji Electric
Power	100VA (max)
Drift	+-1 % of full scale
Material	SS304
Operating Temp.	-5 DegreeC To 45 DegreeC
Measurement Range	0 - 100ppm To 0 - 1% Vol (min)
Max. Measured Concentration	0 - 5000ppm To 0 - 100% Vol (max)
Calibration Intervals	Once in the Month
Dust And Water Resistance	No
Output Signal	Based on the number of measurement
Analog Input	12 Nos
Alarm	5 Nos of Alarm Contact
Warm Up	Not Applicable
Warranty	1 Year
Communication Function	RS-485
Mounting	19" rack mount
Fuel Type	Not Applicable
Shape	Rectangle
Operating Pressure	10 kPa
Battery Backup	Not Applicable
Portable	Not Applicable
Purge Air	Not Applicable
Certification	EN-61000-3-2 (class A)
Automatic Temperature Compensation	Yes
Rechargable Battery	Not Applicable
Touch Screen	No
USB Ports	USB Type-B
Typical Repeatability	+-0.5% of Full Scale
Zero Drift	+-2% of Full Scale/week
Span Drift	+-2% of Full Scale/week
I Deal In	New Only

This gas analyzer is capable of measuring the concentration of NO,SO2,CO2,CO,CH4 and O2 components in sample gas.  NO,SO2,CO2,CO and CH4  are measured by non-dispersion infrared method (NDIR), while O2 is measured by fuel cell, or zirconia method. Up to 5 com- ponents including O2 can be measured simultaneously.
This analyzer is designed with smaller physical dimen- sions. It is well suited for compact analyzing system designs.

In addition maintenance is simplified through adoption of the single-beam system. Optimum use as an analyzer unit of measurement system for combustion exhaust gas from refuse incinerator and boiler, or gas from various industrial furnaces.
