Horizontal Profile Projector
Product Details :
Model 600H
Screen :
- Glass screen - Ø 600mm with crosslines
Magnification :
- 5x, 10x, 20x, 50x, 100x Telecentric Lenses
Workstage :
- Size of Top Plate - 650mm x 230mm
- Measuring Traverse - X:300mm, Y: 200mm
- Load Capacity - 70 Kgs.
- Max Diameter - 220mm
Digital Measuring Systems :
- Linear - 3 axis Simple DRO with Linear Encoders 0.005mm LC
- Angular - 360º rotary encoder LC of 1' of an arc. With digital display Tungsten Halogen lamps
Illumination Systems :
- Profile - 24V, 150W
- Surface - Illumination 24V, 150W - 2 Nos.
Power Supply :
- 220V, 50Hz, 10A
Weight :
- 125 kg ( Unpacked)
Dim :
- ( L x W x H ) 1400 x 840 x 1800
