Throughput

48

48

Fluorescence Channels

4

2

Compatible   Fluorophores

Channel   1: FAM, SYBR Green I, etc.

Channel 2: VIC, HEX, TET, JOE,   etc. Channel 3: ROX, Texas Red, etc.

Channel 4: Cy5,   etc.

Channel   1: FAM, SYBR Green I, etc.

Channel 2: VIC, HEX, TET, JOE,   etc.

Light Source

High-brightness, long-life and maintenance-free LED light source

Detector

Photodiodes   (PDs)

Fluorescence     Scanning Time

48-well 4-channel detection completed within 2s

48-well 2-channel detection completed within 2s

Heating Rate

Maximum heating ramp rate ≥8.0℃/s; Average heating ramp rate ≤6.2℃/s

Cooling Rate

Maximum cooling ramp rate ≥6.2℃/s; Average heating ramp rate≥4.5℃/s

Temperature Accuracy

≤ 0.1℃

Special Temperature   Setting Function

Support thermal gradients PCR, long PCR, Touch Down PCR

Suitable   Consumables

0.2ml clear non-skirt 48-well plates, 8-tube strips, single tubes, etc.

Sample Testing linearity   and

Repeatability

linear Correlation: CV≥0.999

Repeatability: cycle threshold (Ct) value CV ≤0.5%

Software   Analysis

Qualitative analysis, absolute quantitative analysis, relative quantitative analysis, end point fluorescence analysis, melting curve analysis, and genotyping analysis, etc.

Control Method

Stand-alone operation:  7-inch touchscreen control; Cloud-enabled: PC software control via direct connection or LAN (local area network); Up to 10 devices controlled by one

PC

Power Failure   Protection

Automatic recovery of the experiment and other functions when the power is on again   after cutting off, without waiting for the power-on of the computer or software control

Data Storage and   Transmission

A single machine can store more than 1,000 experimental data files, which can be     imported and exported via USB disks

Stand-Alone   Analysis Results

No need for an extra computer: experimental data analysis enabled within the   instrument; Direct printing function (optional) to output the sample  amplification curve and CT value, simply by connecting to the compatible thermal printer

Reporting   Function

Built-in experiment report templates for a variety of industries; Fully open universal   reporting of which the contents and formats can be customized

Operating   System

Windows XP Pro or higher

Power Supply and Power Consumption

AC 100-240V, 50-60Hz; 600VA

Weight

11Kg (net)

Instrument   Dimension

260x400x260mm
