SECTIONED SET OF FOUR DIFFERENT STEERING BOXES (CUTE-044)

SYSTEM DESCRIPTION

Working of high speed moving systems can be studied easily by moving at low speed by external movements. S.P. Tech Equipments have designed the systems, keeping in consideration that all components are exposed & painted with different colours. This makes easy understanding of operation of system. The system is made up from actual working engine/components/systems with a sturdy iron base.

Fig shows the integral type steering system. This unit includes a spool valve, a rotary valve, and a torsion bar. The steering column, steering gear, and steering linkage are little changed from the manual-steering systems.

As the steering wheel is turned, valves are operated to admit this hydraulic pressure to a cylinder that contains the power piston. Then the pressure causes the piston to move, and it provides most of the steering force.

SYSTEM SPECIFICATION:

• Steering Column.
• Steering Gear.

• Steering Linkage.
• Steering wheel.
