SALIENT FEATURES
- Wide Wavelength range, satisfying requirements various fields.
- Fully automated design, realizing the simplest measurement & satisfying the requirement of pharmacopeia
- Maximum of 9 Wavelength & 8 Sample can be measured at one time
- Automatic change - over Between W lamp & D2 lamp
- Optimized optics and large scale integrated circuits design, light source and receiver From world famous measurement methods all add up to high performance and reliability.
- Rich measurement methods: wavelength scan, time scan, multi wavelength Determination multi-order derivative determination, double-wavelength method and triple wavelength methods etc, meet difference measurement requirement
- Automatic 10 mm 8-cell holder
- Data Output can be obtained via a printer port and a USB interface .
- Parameters and data can be saved for user's convenience.
- PC controller measurement can be achieved for more accurate and flexible requirement
Accessories
- Control Unit.
- Cell holder with Peltier System. (It's already pre-loaded into the compartment of the Spectrophotometer).
- Control Cable (to connect the Control Unit with the Cell holder with Peltier System).
- Peristaltic pump pipe. (It's already pre-loaded into the pump valve of the Control Unit)
- Power cord.
Technical specification of peltier/sipper system
- The valid temperature range is from 15°c to 65°C
- The valid sampling time range is from 30s to 10min
- The valid peristaltic pump speed range is from 1 to 12
- The sampling speed is about 50ml/min.
- Power supply is 220+221@50+1Hz or 110+111@60+1 Hz.
Applications
- Medicine/Pharmaceutical Industry
- Environment Monitoring
- Commodity Inspection
- Food Inspection
- Agricultural Chemistry
- Teaching in Colleges & Universities
- Metallurgy
- Geology
- Machine Manufacturing
- Petrochemical Industries
- Water and Waste water Labs
- Food and beverages Labs
TECHNICAL SPECIFICATIONS
Optical System | Double Beam ( 1200 Lines/nm Grating ) |
Wavelength Range | 190-1100nm |
Mode | Basic/Quantative/Wavelength Scan/DNA Protein Test/Kinetics/Multi Wavelength Mode |
Scanning Speed | Fast/Medium/Low |
BandWidth | 0.5/1.0/2.0/4.0 nm. |
Wavelength Accuracy | +0.3nm |
Wavelength Repeatability | 0.2nm |
Photometric Accuracy | +0.3 % T |
Photometric Repeatability | 0.2 % T |
Photometric Display Range | 0-200% T,-0.3 -3.0A, 0 - 9999 C |
Stability | 0.001 A/h @500 nm |
Baseline Flatness | + 0.001A |
Noise | + 0.001A |
Stray Light | < 0.05%@220nm&360nm |
Data Output Port | USB |
Printer Port | Parallet Port |
Display | Graphic LCD ( 320x240 Dots ) |
Lamps | Deuterium Lamp & Tungsten Halogen Lamp |
Detector | Silicon Photo diode |
Packing Dimension | 625 X430X 206 nm |
Weight | 30 kg |
