Thermal Imaging Solutions
Product Details:

Brand	Land AMETEK
Model	NIR-BORESCOPE 3XR
Temperature Range	600 to 1800 DegreeC / 1112 to 3272 DegreeF
Accuracy	1.0 % Celsius
Field Of View	90 Degree
Dimensions (With Standard Lens And Battery)	254 x 560 x 717 mm (or 1021 mm or 1326 mm) 10" x 22" x 32" (or 44" or 56")
Power Rating	21.6 - 26.4 V dc, 0.6 A
Probe Length	305, 609 or 914 mm (12", 24" or 36")
Mounting	Choice of 3" ANSI 150 RF Flange & Gasket or PN16 DN80 Flange & Gasket with a 12" standpipe

GENERAL DESCRIPTION:The NIR Borescope (NIR-B) 3XR is a short wavelength radiometric infrared borescope imaging camera for steam reformer and cracker tube continuous temperature measurement and furnace optimisation and monitoring.With the NIR-B 3XR it is possible to use the proven technology of the NIR Thermal Imager to accurately and continuously profile the temperature of the reformer, improving data accuracy through automation and at the same time reducing the risk to personnel byremoving the need for an operator to be in the hazardous area
on a regular basis.With advanced digital communications the image and data can be viewed real-time in the control room in the safe Area.
FEATURES & BENEFITS:
High temperature measurement accuracy - enables optimum process control through enhanced thermal imaging
Short wavelength sensor - low sensitivity to emissivity changes
24 Hour, 7 Day Monitoring - Shutterless operation guarantees
accurate, reliable data with no blind time
3 Year Warranty -guarantee of reliability
Dedicated software - data points, areas of interest, automated alarms and long term data trending and system inter-connectivity (DCS, OPC)
APPLICATIONS:
Hydrogen Reformer
Ammonia Production
Ethylene Cracking Furnaces
Methanol Production
Syngas Production
