Torsion Testing Machine

Brand	Enkay Enterprises
Frequency	50 Hz
Voltage	415 V
Torsional Speed	0.1/0.2 RPM
Power Source	Electric

Torsion Testing Machine is designed for conducting Torsion and Twist on various metal wires, tubes, sheet material. Torque measurement is through torque sensor and the twist angle is measure through rotary encoder. Both the parameters are displayed on the digital display in their respective engineering units. Digital display is state of the art microprocessor based unit for display and with facility for transferring data to the computer. If connected to the computer on line graph of Torque versus Angle of rotation can be seen on the monitor. (Computer does not form the part of the supply.) The accuracy of the torque indication is better than ±1% of the true torque. Various grips as mentioned in the table are provided as standard with the system.


Specification:

• Unique 'TALON-CLAW' Grips for Round and Flat Specimens
• Torque Compensated Motors
• Maintenance Free Gear Box
• Auto Range Selection with Range Selector Wheel (Optional)
• 3 or 4 Torque Ranges for Higher Accuracy (Optional)
• Load-unload Capability
• Variable Speed Drive (Optional)

Also in our Range of Manufacture

• Electronic Microprocessor based version with Digital Indication of Torque and Angle of Twist
• Computerized Version
