Track Jack - MAMCO
Product Details:

Minimum Order Quantity	1 Piece
Vehicle Type	Railway Track
Brand	MAMCO
Body Material	Steel casting
Base and Head Material	Mild steel plate of ample thickness
Head Capacity	15 T
Foot Capacity	7.5 T
Closed Height	558 mm
Lift	50 mm
Floor Lift Height	304 mm
Base Size	160 x 280 mm
Head Size	76 mm Sq

End Use

• The MAMCO Track Jacks are the most general purpose Jacks. Rugged construction permits safe Lifting & Lowering of Railway Tracks for Leveling & Maintenance.
• MAMCO Jacks can be use in Oil Fields, Shipyard, Mining Operations, Construction, Heavy Duty Industrial Maintenance & Establishment.


Special Features:

• MAMCO Double acting trip & Ratchet Lowering Track Jacks can be raised on both up & down stroke of lever.
• MAMCO Track Jacks are Anti - Skid cap and toe support to lift full rated capacity.

• Close fulcrum and correct socket angle provide high mechanical efficiency.
• Heat-treated, forged components for extra strength and longer life

• Both pawls are spring loaded to assure engagement of teeth with rack.
• Every MAMCO Track Jack is guaranteed to full load capacity.


Other Details:

Manufacturing Tolerance- + /- 5 mm
