Specifications:
- Temperature Range: Above ambient to 450° C/600° C
- Temperature Control : By Microprocessor Based Auto Tune 4 Digit PID Controller.
- Display: Set Value Indication [SV] Digital Window
- Process Value Indication [PV] Digital Window.
- Resolution : 0.1° C
- Reference Indicator Controller : By Calibrated PID Controller having universal input for RTD or Various type of thermocouples or millivolt or milliamp selectable by front feather touch keys.
- Timer : A Digital Timer pre-settable up to 999 minutes provided and after elapse of pre-set Time the unit will be automatically off.
- Accuracy: /- 0.1 % FS.
- Stability: /- 0.5°C.
- Heating Time: From ambient to max. Within 30 to 45 Min.
- Cooling Time: Max.60 Min.to brings down the temp. up to approx.100° C by Built in force air cooling.
- Wattage/Power Consumption: Approx.1200 W or as required.
- Well Depth: To suit ½” & ¼”, ” probes. 1 no. each. Or 6, 8, 10, 15,20mm.
- Line Voltage: 220V AC Single phase 50Hz /- 5%.
