High Temperature Furnace

Product Details :

Manufacturer of Muffle Furnace for 900 degree, 1200 degree, 1400 degree and 1800 degree.We are the leading High Temperature Furnace manufacturer, these lab furnaces (0-1500 DegreeC) are specially designed to meet the requirements of high temperature applications. In these furnaces, the casing is manufactured using MS reinforced with iron angles. Along with this, the chamber of these furnaces is made of ceramic Zirconium Board having horizontally placed elements. Heating is carried out through silicon carbide rods and controlled through transformer. The furnaces have large surface radiation ratio to enhance thermal efficiency and reduce power consumption. There is a control panel fitted with the furnaces and having digital temperature indicator cum controller.

Features of High Temperature Furnace

• Maximum furnace Temperature upto 1450C
• Working Temperature up to 1400C
• Operable in 220 volts Single Phase AC supply

Chamber Size (mm)

• 100 x 100 x 225
• 125 x 125 x 250
• 150 x 150 x 300
• 200 x 200 x 300

Optional Accessories with High Temperature Furnace Digital Temperature Controller cum Indicator (P.I.D. Based)
