Muffle Furnace

Product Details:

We are manufacturer, supplier & distributor of Muffle Furnace. Muffle Furnace are specially designed to suit IS & ASTM Standard. IT is applied in growing fields of Medical Research, Agricultural, Industrial, Metal Treatment, Ash Determination & Wool Industries.

Technical Specifications:

Outside Body made of G.I. Sheet powder coated Inner muffle of Ceramic with high grade ceramic instillation Door insulation of HFK briks Heating element are made from kanthal A1 Wire A Uniform distribution through all 4 sides with kentahl wire Max. Working temp upto 1160 C Equipped with digital temp. Controller cum indicator fitted on top side of the unit with indicating lamps & switches A special type of thermocouple fuse for safety to avoid over heating Power supply 230 Volts, 50 H2

Optional Accessories:
Digital Timer Solid state fuses for extra safety PID Controller with printer interface Industrial Muffle Furnace is available in below Sizes:

Inner Dimension	Outer Dimension	Rating K.W.	Power consumer	Net weight
9"x4"x4"	18"x14"x14"	2	9	30 KG
10"X5"X5"	19"X15"X15"	2.5	11	40 KG
12"X6"X6"	21"X17"X17"	3.5	15	55 KG
18"X9"X9"	28"X20"X20"	6	26	80 KG
