Specifications are as below:-
- Sensing Mode (General)-Proximity
- Sensing Mode (Detailed)-Background Suppression (Fixed)
- Housing Style-Rectangular w/M18 Mount
- Primary Housing Material-Thermoplastic
- Max Sensing Range (mm)-100
- Outputs-NPN
- Power Supply/Supply Voltage-10-30 V dc
- Connection-2 m Cable
- Quick Disconnect Type-No QD
- Sensing Beam-Visible Red LED
- Operation-Light/Dark Operate
- Max Op. Temp. (°C)-70
- Min Op. Temp. (°C)- -20
- Output response time (ms)-0.85
- Special Feature: Intrinsically Safe-No
- Special Feature: Remote Teach-No
- Special Feature: Water Detection-No
- IP Rating-P67
- Laser Classification-N/A
- Delay at Power-up (ms)-100
- Repeatability (µs)-160
- Number of Pins-4
- NEMA Rating NEMA-6
- Max Op. Relative Humidity [%]-95% @ 50°C
- Lens Material-Acrylic
- Adjustments-N/A
- Barrel Diameter (mm) -18
- Indicator-LEDs
- Opposed Mode Emitter/Receiver-N/A
- Feature: Timing (Hold/Delay)-No
- Feature: Encapsulated-No
- Feature: Hazardous Area-No
- Feature: Audible-No
- Input/Output-Discrete
