Mode

General

Serum

Urine

Range

Na: 0.1-100 ppm
Upto 250 meq/l, 1:100 dil

K: 0.1-100 ppm
Upto 250 meq/l, 1:100 dil

Ca: 15-100 ppm
Upto 250 meq/l, 1:100 dil

Li: 0.5-100 ppm
Upto 250 meq/l, 1:100 dil

Na: 0-200
1:100 dil

K: 0-10
1:100 dil

Ca: - Li: 0-2
1:5 dil

Na: 0-250
1:100 dil

K: 0-100
1:100 dil

Ca: - Li: 0-10
1:2 dil

Sensitivity

General Mode: Na:0.5 ppm, K:0.5 ppm, Li:0.5 ppm, Ca:15 ppm

Filters

Na K Supplied (Ca Li are optional at extra cost)

Resolution

0.1 ppm/meq

Reproducibility

+ 2% FS, ± 2 Digits

Curve Fit Accuracy

+ 2% FS

Display

20 x 4 Alphanumeric backlit LCD display

Average Time

In-built in Software

Flame System

LPG dry oil free air

Detector

Silicon Photodiode

Calibration

Upto 5-Point Calibration with curve fitting software

Gas Control

Adjustable with knobs

Ignition System

Auto Ignition

Automiser

Axial flow type

RS-232C Interface

Available (PC Software at extra cost)

Power

230 V + 10% AC, 50 Hz

Dimensions

365 x 245 x 220 mm (L x B x H) (Approx.)

Weight

Main Unit : 7.5 Kg. (Approx.)

COMPRESSOR UNIT

Air Supply

By oil free mini compressor unit with pressure regulator

Combustion Gas LPG

Controlled by precision regulator

Power

230 V + 10% AC, 50 Hz
