Feature:
- Useful for both ppm and meq application.
- Measurement of four elements with single aspiration.
- Automatic filter selection.
- Curve fitting software (up to 5 Standards)
- Calibration stored in memory.
- Re-standardization facility with only one standard.
- User friendly menu driven software.
- Help key available at each & every operating step.
- 20 Character x 4 Line alphanumeric LCD display.
- Measurement results stored in memory.
- Measured results can be recalled on display & printed.
- Measurement results can be printed (Individual, Batch-wiser & Date-wise).
- RS 232 interface
- Air Compressor with air regulator & in-built air filter.
- Facility for storage of Date & Time of results.
- Auto Ignition Facility
TECHNICAL SPECIFICATIONS
Model | 11-1382 |
Range | Na: 0-100 ppm Upto 250 megil, 1: 100 dil. K: 0-100 ppm Upto 250 megil,
1: 100 dil. Ca: 0-140 ppm Upto 250 meq/I, 1: 100 dil. Li: 10-100 ppm Upto 250 med/1,
1: 100 dil. |
Sensitivity | Na: 0.1 ppm, K: 0.01 ppm, Ca: 0.5 ppm, Li: 10 ppm |
Optical Management | Simultaneous analysis of 3 elements |
Filter | Microprocessor controlled stepper motor with |
Selection | 0.5 KVA stabilizer |
Units | ppm, mg and % age Selectable |
Reproductivity | ±1% FS ±1 Digits |
Curve Fit Accuracy | ±2% of FS |
Display | Large LCD display 20x4 lines graph through Rs232 |
Aspiration | 4-5 Seconds |
Time Scale Range | 0 to 100% Sensitivity for full scale |
Flame System | LPG & Dry Oil free air |
Detector | Photodiode |
Calibration | Up to 5 point Calibration with curve fitting software |
Gas Control | Adjustable with knob |
Ignition | Auto Ignition |
System Fuel Gas | LPG |
Burner | Stainless Steel |
Dimensions | 365x245x224 mm Approx. (LxBxH) |
Printer | Provision for attachment of Dot - Matrix printer of HP
Laser-Jet/Inkjet printer (non-win printers) with Centronics parallel
interface |
RS232 Interface | Rs232 Connector interface available (PC Software at extra Cost) |
Air Compressor | With Built-in Regulator & Air filter to deliver stable &
Moisture/oil free air supply r 1 kg/cm2 |
Air Supply | By Oil free mini Compressor unit with pressure regulator |
Weight | Main Unit: 8 kg (Approx.), Compressor: 6.5 kg. (Approx.) |
Power Supply | 95 to 270V AC 50-60 Hz with inbuilt stabilizer |
Blank Air Supply Combustion Gas | By oil controlled by precision regulator LPG controlled by precision regulator |
Power | 230V ± 10?, 50Hz |
Dimension | 270W x 192H x 240D mm |
Weight | 6.25 kg. (Approx) |
Operation Manual | 1 No. |
Dust Cover | 1 No. |
Mains Lead | 1 No. |
Air Pipe, Drain Pipe | 1 Meter each |
Gas Connection tube | 2 Meters |
Chimney | 1 No. |
Capillary Tubes | 1 Meter |
Cleaning wire | 1 Set |
Hose clamps | 4 Nos. |
Gas Ignitor | 1 No. |
