Shallow Posthole Seismometers
Product Details :
Shallow Posthole Seismometer: Model F72-2.0
Easily installed Seismometer for micro-earthquake monitoring.
The F72-2.0 is IESE’s readily deployed shallow posthole sonde for use in micro-earthquake detection and analysis. The standard model F72- 2.0 is designed for installation in up to 50 m vertical holes with a specialized option for use to 100 m. All three orthogonal components are fixed. The F72-2.0 represents a low cost compromise if the conditions are applicable. An alternate model, the F72-4.5 offers a higher tilt tolerance in exchange for a higher corner frequency.
Features:
- Fixed geophones
- Withstands up to 100 °C (frequency changes > 50 °C)
- Passive sensors
- For permanent or semi-permanent installations
- Custom versions can include accelerometers, magnetometers etc.
F72-2.0 Shallow Posthole Seismometer Specifications
Geophone Parameter | Specifications |
|---|---|
Sensor Configuration: | Triaxial, Orthogonal |
Natural Frequency: | 2.0 Hz |
Operational Temperature: | -45°C to 100°C |
Geophone Tilt Tolerance: | Ver: ± 7.5°, Hor: ± 0.5° |
DC Resistance: | 3,810 Ω |
Sensitivity: | 0.787 V/cm/s |
Transduction Constant: | 0.0126 √Rc V/cm/s |
Open Circuit Damping: | 0.61 |
Moving Mass: | 23 g |
Max Coil Excursion p-p: | 0.76 cm |
Housing Parameter | Specifications |
|---|---|
Operational Pressure: | 0.55 Mpa |
Outer Diameter: | Ø 72 mm |
Wall Thickness: | 2.5 mm |
Height: | 315 mm |
Weight: | 11 Kg |
Casing Material | SS 316L |
Shallow Posthole Seismometer: Model F72-4.5
Easily installed Seismometer for high temperature micro-earthquake monitoring.
The F72-4.5 is IESE’s readily deployed shallow posthole sonde for use in micro-earthquake detection and analysis. The standard model F72- 4.5 is designed for installation in up to 50 m vertical holes with a specialized option for use to 100 m. All three orthogonal components are fixed. The F72-4.5 represents a low cost compromise if the conditions are applicable. An alternate model, the F72-2.0 offers a lower corner frequency in exchange for a lower tilt tolerance.
Features:
- Fixed geophones
- Withstands up to 150 °C
- Passive sensors
- For permanent or semi-permanent installations
- Custom versions can include accelerometers, magnetometers etc.
F72-4.5 Shallow Posthole Seismometer Specifications
Geophone Parameter | Specifications |
|---|---|
Sensor Configuration: | Triaxial, Orthogonal |
Natural Frequency: | 4.5 Hz |
Operational Temperature: | -45°C to 150°C |
Geophone Tilt Tolerance: | Ver: ± 15°, Hor: ± 2° |
DC Resistance: | 3,810 Ω |
Sensitivity: | 0.787 V/cm/s |
Transduction Constant: | 0.0126 √Rc V/cm/s |
Open Circuit Damping: | 0.27 |
Moving Mass: | 23 g |
Max Coil Excursion p-p: | 0.76 cm |
Housing Parameter | Specifications |
|---|---|
Operational Pressure: | 0.55 Mpa |
Outer Diameter: | Ø 72 mm |
Wall Thickness: | 2.5 mm |
Height: | 315 mm |
Weight: | 11 Kg |
Casing Material | SS 316L |
