Modular Circular Polarimeter:

MCP

Model: MCP-5100

• The entry-level instrument of Anton Paar’s high-end polarimeter family
• Accuracy of ±0.0025 °Optical Rotation
• Peltier temperature control at 20 °C & 25 °C
• Modular concept for instrument upgrades, e.g. multiple wavelengths
• Full compliance to all relevant standards, e.g. 21 CFR Part 11

Model: MCP-5300

• The mid-range instrument of Anton Paar’s high-end polarimeter family
• Accuracy of ±0.0020 °Optical Rotation
• Peltier temperature control range from 10 °C to 45 °C
• Modular concept for instrument upgrades e.g. multiple wavelengths
• Full compliance to all relevant standards, e.g. 21 CFR Part 11

Model: MCP-5500

• The high-end instrument of Anton Paar’s high-end polarimeter family
• Accuracy of <0.0020 °Optical Rotation
• Peltier temperature control range from 10 °C to 45 °C
• Built-in camera for visualization of sample filling inside the cell
• Full compliance to all relevant standards, e.g. 21 CFR Part 11

The high-end MCP polarimeter series combines state-of-the-art technology, modern design, and great usability. Customer-specific configurations like multiple wavelengths provide the widest range of options to keep your polarimeter fit for the future. MCP 5100/5300/5500 is the perfect solution for measuring the optical rotation and determining the concentration or specific rotation of optically active substances for the pharmaceutical, cosmetic, and chemical industries, as well as for R&D. Its modern data management – fully compliant with 21 CFR Part 11 – provides data integrity no matter whether the polarimeter is operated as a stand-alone or desktop-PC-controlled setup, or connected to the network.

Key Features :

External MCP desktop software, taking care of all data administration

The polarimeter is controlled by the external MCP desktop software. All interaction takes place on the connected PC. User group, system, and data administration will be performed by the computer, not by the instrument, so the time to qualify the instrument is immensely decreased. Lifetime data (measured data, audit trail, check, and adjustment) is automatically stored as raw data in the desktop database. This database can be backed up and restored on demand by customer IT processes.

Raw Data Viewer for data authenticity check

The MCP polarimeter is connected to the network or PC via Anton Paar LIMS Bridge to collect or administrate data. The Anton Paar Raw Data Viewer provides the plausibility check, meaning that archived raw data can be loaded and regenerated from machine-readable into human-readable format for the verification process. Automatic checks verify the integrity of digitally signed data – in case of changes the file verification will be rejected.

Comprehensive qualification documentation

With the Anton Paar Pharma Qualification Documentation, your new MCP polarimeter is integrated into your workflow within a short period of time.

IQ/QO/PQ as well as a risk analysis and 21 CFR Part 11 checklist are provided. A local Anton Paar employee will carry out the instrument qualification together with you – this saves you time and money.

Modular concept to grow with your requirements

Your investment in an MCP polarimeter is secure, no matter which measurements you will face in the future. All MCP models can be upgraded, e.g. with additional wavelengths, air pump, or FillingCheck camera to meet new requirements. Up to eight spectral filters in the UV/VIS/NIR ranges can be added to the instrument right away or later on as a field upgrade.

Technical highlights for maximum reliability

The MCP polarimeters equipped with features for the highest traceability and reliability:

• Wireless Toolmaster™ technology – automatic identification of sample cells and quartz control plates
• FillingCheck™ – built-in camera to monitor real-time images of the filling process (optional for MCP 5100/5300)
• Automatic Peltier temperature control – eliminates the need for a thermostatic water bath
• LED light source – maintenance-free for 100,000 hours
• Built-in air pump to discharge the sample from the cell, clean and dry the sample cell inside (optional for MCP 5100/5300)
• Up to eight spectral filters in the UV/VIS/NIR ranges (optional)

Wide range of sample cells ready for your application

A variety of sample cells available in different path lengths, materials, and filling options meet all your possible requirements. All MCP polarimeter sample cells come with wireless technology supporting the Toolmaster™ function. Cell type and master data are automatically transferred to the instrument. MCP automatically checks if the cell meets the selected method settings. Live temperature data is also transmitted to the instrument.

Whatever the application, Anton Paar provides the suitable sample cell.
