Projection Microscope

Ideal for quick and reliable specimen assessment and for determining if metallurgical properties meet manufacturing specifications.

Infinity corrected LWD Plan Achromatic objectives provides brilliant images with superb images.

Ergonomics hands rest on both sides of mechanical stage strain free operation.

Specifications:

Warranty Information 2 Years parts.

1 year Electronics

Stand	Single mold sturdy stand with anti rust materials. Extended base for better stability.
Observation Head	Trinocular head with observation head 30º rotatable at 360º. Interpupillary distance from 55mm to 75mm. Phototube for microphotography. Diopter adjustment ring on ocular provides correction for eye acuity.
Eyepiece	Wide Field Eyepieces 10X (PAIRED) FOV 20mm.
Nosepiece	Reverse angle quadruple nosepiece revolves on ball bearing with positive indexing. Soft rubber knurled grip on nosepiece.
Objectives	Long Working Distance Plan Achromatic 5X. Long Working Distance Plan Achromatic 10X Long Working Distance Plan Achromatic 20X (SL). Long Working Distance Plan Achromatic 50X (SL)Dry.
Stage	Mechanical stage Size 150mmX200mm, supported on ball bearing guideways and having low positioned co-axial controls for stage movement. Hand rests provided on both sides.
Focusing	Co-axial focusing control with ball bearing guideways & large knobs, pre focusing lever & tension adjustment ring. The slow motion has 1DIV=0.002mm
Illumination	The Epi illuminator has 6V/20W halogen lamp, adjustable brightness.
Packaging contents	Blue, Green, & Yellow filters. STYRO FOAM Molded pack.

Polarizing Outfit

Analyser rotatable 360º. Polarizing & Analyser can be slided in/ out of the optical path.

Projection Microscope MHL-47
